Operational Limits: Minimum inner turning radius of 4.0m and outer radius of 6.4m. Recommended minimum laneway width of 3.0m and tunnel height of 2.7m.
| ITEM NO. | NAME | TECHNICAL INDICATORS | NAME | TECHNICAL INDICATORS |
|---|---|---|---|---|
| 1 | Overall dimensions (mm) | 9800×2200×2000 | Explosion-proof power (KW) | 190 |
| 2 | Structure type | Shovel type, front and rear frame hinged | Minimum ground clearance (mm) | 320 |
| 3 | Vehicle curb weight (Kg) | 31000 | Loading capacity (Kg) | 25000 |
| 4 | No-load speed (km/h) | 0-20 | Full load speed (km/h) | 0-17.5 |
| 5 | Driving operation | Driving sideways | Adapt to hydraulic support type | weight ≤ 25T |
| 6 | Transmission form | Hydromechanical Transmission | Drive mode | 4×4 four-wheel drive |
| 7 | Number of brake wheels | 4 | Braking form | Wet spring brake |
| 8 | Working braking distance (mm) | ≤ 5000 | Emergency braking distance (mm) | ≤ 5000 |
| 9 | External turning radius (mm) | ≤ 6400 | Inner turning radius (mm) | ≤ 4000 |
| 10 | Steering method | Hydraulic steering | Maximum climbing ability | 16° |
| 11 | Max lifting angle of shovel | 11° | Max downward swing angle | 14° |
