Discount Custom Pneumatic Rod Seals NBR / SAC Material For Open Grooves Exporters, Exporter

Custom Pneumatic Rod Seals

SAC Pneumatic Rod Seals

Pneumatic NBR Seal

Place of Origin:

CHINA

Brand Name:

KELONG

Model Number:

KL-76

Product Description

📦 Product Specifications
Product Name Custom Pneumatic Rod Seals
Material NBR SAC
Temp Range -30 / +105 °C
Sliding Speed (max) 1.0 M/s
Max Pressure 16 Bar
Application Pneumatic Cylinders
💳 Commercial Terms
Minimum Order 100 Pieces
Packaging Customizable
Delivery Time 15 Days
Payment Terms L/C, T/T
🌟 Key Advantages

KL76 pneumatic rod seal is a single acting sealing element made of high-quality elastomer material. It features an integrated metal ring body inside, designed specifically for use in open grooves, ensuring structural integrity and stability.

  • Superior wiping and sealing performance
  • Excellent adaptation to temperature changes
  • High quality raw material: Dust, Water, and Oil proof
  • Wear resistance for extended service life
  • Stable performance during high-speed rotation
  • Wide range of available dimensions
📍 Area of Application

Recommended for use in professional pneumatic systems and cylinders complying with standard industrial specifications:

  • Pneumatic Cylinders
  • ISO 6432 Standard Cylinders
  • ISO 21287 Compact Cylinders
❓ Frequently Asked Questions
What is the primary material used for these rod seals?
The seals are manufactured using high-quality NBR SAC elastomer material with an internal metal ring for enhanced stability.
What are the pressure and temperature limits?
These seals can handle a maximum pressure of 16 Bar and operate efficiently within a temperature range of -30°C to +105°C.
Are these seals compatible with ISO standard cylinders?
Yes, they are highly recommended for use in pneumatic cylinders according to ISO 6432 and ISO 21287 standards.
How do they perform in high-speed applications?
The KL76 seals are designed to remain stable and provide a good sealing effect even in high-speed rotations up to 1.0 M/s.
Can the packaging be customized for bulk orders?
Yes, we provide customizable packaging details to meet specific client requirements for shipping and storage.
What is the supply capacity for this product?
We have a robust supply ability of approximately 100,000 pieces per month to ensure consistent availability.
